XR0170-3P
3 pole XLR female receptacle, vertical PCB mount, Nickel housing, silver contacts
Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling
Download Data Sheet
Features & Benefits
Download
Technical Information
| Product | |
|---|---|
| Model | XR0170-3P |
| Connection Type | XLR |
| Gender | female |
| Electrical | |
|---|---|
| Contact resistance | ≤ 5 mΩ |
| Dielectric strength | 1.5 kVdc |
| Insulation resistance | > 10 GΩ(initial) |
| Rated current per contact | 6 A |
| Rated voltage | < 50 V |
| Mechanical | |
|---|---|
| Lifetime | > 1000 mating cycles |
| Wiring | Vertical PCB mount |
| Locking device | Latch lock |
| Material | |
|---|---|
| Contacts | Phosphor bronze |
| Insert | Polyamide (PA66) |
| Locking element | Steel S65C |
| Shell | Zinc diecast |
| Shell plating | Nickel |
